JBM-EX33 Biological Microscope equipped with a super large ceramic rackless stage, super endurance function, ECO energy-saving working mode, and user-friendly design to increase comfort and safety in medical, biological, and clinical labora...
JBM-EX33 Biological Microscope equipped with a super large ceramic rackless stage, super endurance function, ECO energy-saving working mode, and user-friendly design to increase comfort and safety in medical, biological, and clinical laboratory environments.
| Technical Parameters | Specification |
|---|---|
| Brand | JB Microscope |
| Model No | JBM-EX33 / JBM-PL12 |
| Viewing Head | 30 degree inclined Trinocular head, with locking mechanism for eyepieces, right diopter adjustment: ±; interpupillary distance range: 50-75mm |
| Eyepiece | Wide field plan eyepiece PL10X/22mm, with reticle, diopter adjustable |
| Objective | Plan achromatic objectives 4X / 10X / 20X / 40X / 100X (Oil) |
| Stage | Double layers, mechanical ceramic paint stage, precision: 0.1mm (x-axis rackless), clips for double sliders, moving range 78mm x 51mm |
| Nosepiece | Quadruple nosepiece |
| Condenser | N.A. 1.25 Koehler illuminator condenser (with socket for phase contrast and dark field accessories) with aperture diaphragm |
| Fluorescent Reflection System | B4 TB-LED fluorescent module for TB, with intensity adjust knob, BF/FL switching knob, central wavelength 455mm |
| Illumination System | 100V-240V External transformer, 3W LED with continuous intensity control. Type-c interface allows portable battery power. USB port with ECO function. |
| Camera Accessories | 0.5X camera adaptor, focusing adjustable |
