Metallographic microscope is mainly suitable for electronics, metallurgy, materials, semiconductors, chemical industry and instrumentation industries to observe transparent, translucent or opaque objects, that is, objects that need to be il...
Metallographic microscope is mainly suitable for electronics, metallurgy, materials, semiconductors, chemical industry and instrumentation industries to observe transparent, translucent or opaque objects, that is, objects that need to be illuminated by transmitted light or reflected light, such as, integrated blocks, printed circuit boards, liquid crystal panels, films, fibers, textiles, coatings another non-metallic materials. The upright metallographic microscope is also suitable for medicine, agriculture and forestry, schools, military industry and scientific research departments for observation and analysis.
| Product Features | Technical Parameter |
|---|---|
| Brand Name | JB MICROSCOPE |
| MODEL | JBM-UM50 |
| Stage | 140mmX120mm double-layer movable platform |
| Stage Moving Range | 80mmX50mm |
| Focusing | Coarse and fine focusing, using gear rack transmission mechanism, fine-motion value 0.002mm |
| Condenser | NA1.25 swing Abbe condenser with variable aperture |
| Lighting Source (Upper) | Upper lighting LED lamp 5W, DC12V2A, brightness adjustable |
| Lighting Source (Down) | Down lighting LED light 5W, DC12V2A, adjustable brightness |
| Light Collecting Mirror | High brightness fixed lighting with adjustable light bar |
| Magnification | Numerical Aperture | Working Distance (mm) |
|---|---|---|
| 5x | 0.12 | 23.6 mm |
| 10x | 0.25 | 17.7 mm |
| 20x | 0.40 | 10.4 mm |
| 50x | 0.55 | 7.0 mm |
